STANDARD FEATURES:

16″ On Center Cross Members
24″ On Center Tubing Roof Members
16″ On Center Tubing Sidewalls
.080 Polycor
Semi-Screwed Exterior
3/8″ Plywood Walls
3/4″ Plywood Floors
Interior Height 78″
ST205 15″ Radial Tires
3500 lb. Drop Leaf Spring Axles
Aluminum Fenders
7 way plug
2 5/16″ Coupler
Galvalume Roof
Side Door with ATP covered Stepwell
Heavy Duty Ramp Door with Flap
2000 lb. A-Frame
Jack with Sand Foot
E-Z Lube Hubs
V-Nose with 24″ Stone Guard
Door Hold Back
12-volt Dome Light
LED Full Light Package
Side Wall Vents
No show Beavertail
6″ Steel Tube Main Frame

SPECIFICATIONS (may change with upgrades)

Dimensions:  Interior Length: 16′ Plus 2′ V Nose | Interior Width: 96″ | Interior Width Between Wheel Wells: 83″ | Overall Length: 19′ 10″ | Overall Width: 102″ | Overall Height: 97″ | Hitch Height: 20″

Ground Clearance: 14″ to bottom of the frame | Rear Ramp Door Width: 91″ | Rear Door Height: 72″
Tires: ST 205/75R15/5 Lug

Weight:  Empty Weight: 2800 lbs.  | Tongue Weight: 420 lbs.  | Payload Capacity: 4200 lbs. with a 3500 lb. Axle | Payload Capacity: 7600 lbs with a 5200 lb. Axle | GVWR: 7000 lbs. with 3500 lb. axles
